Automatic Graphic Die CNC Knife Cutting Plotter Machine for Cardboard Box Carton Kraft Paper Vinyl Sticker Label Plastic PVC

Description Review

Description

Features:
DEVEUP DT series digital cutting equipment integrates oscillating kinife cutting tools, creasing wheel tools, kiss(half-cutting) cutting tool, drag tool, drawing pen tools and precision industrial CCD camera visual positioning system. According to your original artwork design, it can realize the cutting and creasing of creative designs of any shape. This product can be used for sample making and small scale production in the industries of packaging, printing, advertisement, etc.

Advantages:
1. No need mould: simply export the design in Illustrator or CorelDRAW in PLT, DXF format.
Send it to the onboard software and the subsequent process will be executed automatically. No need to make mould, saving time and cost of tooling.
2. Personalized small batch unattended: Designed for short run production, it takes typically 15-70 seconds (depending on the complexity of the shape) to process A3 - B2 size labels or card stock.
3. Quiet and environmentally friendly: working noise of 65 dB, cutting without smoke and odor, can be used in a variety of office environments.

Specifications:

Technical parameters / model	DT-4060 DT-6080 DT-1290
Effective working area	400600mm 600800mm 1200*900mm
Muitfunctional head	Oscillating knife cutting tool, kiss-cut/half cut tool, bevel cutting tool, creasing wheel,CCD camera, dotted line cutting tool, marking pen
Safety devices	Safety devices use infrared sensing, safe and reliable
Cutting speed	2000mm/s
Cutting thickness	≤45mm Other thicknesses can be customized according to the material
Applicable materials	Paper, cardboard, carton box, sticker, pvc card, id card, ablel, vinyl sticker, corrugated paper, honeycomb carton, pp, Kt board,grey board, coated paper, and etc
Transmission port	Network port
Transmission system	servo motor, linear linear guide, timing belt, lead screw
Rated power	3kw
Rated voltage	220V±10% Optional
Operation Panel	Multi-language touch screen operator panel
Support file format	AI,PLT,DXF
Operating environment	Operating environment Temperature 0-40°C Humidity 20%-80%RH

Technical parameters / model DT-6080 DT-1290 Effective working area 600*800mm 1200*900mm Muitfunctional head Oscillating knife cutting tool, kiss-cut/half cut tool, bevel cutting tool, creasing wheel,CCD camera, dotted line cutting tool, marking pen Safety devices Safety devices use infrared sensing, safe and reliable Cutting speed 2000mm/s Cutting thickness ≤45mm Other thicknesses can be customized according to the material Applicable materials Paper, cardboard, carton box, sticker, pvc card, id card, ablel, vinyl sticker, corrugated paper, honeycomb carton, pp, Kt board,grey board, coated paper, and etc Transmission port Network port Transmission system servo motor, linear linear guide, timing belt, lead screw Rated power 3kw Rated voltage 220V±10% Optional Operation Panel Multi-language touch screen operator panel Support file format AI,PLT,DXF Operating environment Operating environment Temperature 0-40°C Humidity 20%-80%RH Cutting Samples: Technical parameters / model DT-6080 DT-1290 Effective working area 600*800mm 1200*900mm Muitfunctional head Oscillating knife cutting tool, kiss-cut/half cut tool, bevel cutting tool, creasing wheel,CCD camera, dotted line cutting tool, marking pen Safety devices Safety devices use infrared sensing, safe and reliable Cutting speed 2000mm/s Cutting thickness ≤45mm Other thicknesses can be customized according to the material Applicable materials Paper, cardboard, carton box, sticker, pvc card, id card, ablel, vinyl sticker, corrugated paper, honeycomb carton, pp, Kt board,grey board, coated paper, and etc Transmission port Network port Transmission system servo motor, linear linear guide, timing belt, lead screw Rated power 3kw Rated voltage 220V±10% Optional Operation Panel Multi-language touch screen operator panel Support file format AI,PLT,DXF Operating environment Operating environment Temperature 0-40°C Humidity 20%-80%RH
